PX-MFC 90 D Lab mill with hammer grinding, 100 – 120 V
Availability:In stock
Estimated Delivery: 8-10 Weeks
SKU
LBX-KIM-0294
The PX-MFC 90 D Lab Mill offers reliable, precise grinding for laboratory applications. Its hammer grinding system, paired with a 2.0 mm sieve and easy-to-switch attachments, enables efficient sample preparation. Ergonomically designed for user safety, it grinds down to 40µm particle size, making it ideal for labs requiring versatile and dependable performance in quality control and analysis.
BrandKinematica
| Product Name | PX-MFC 90 D Lab mill with hammer grinding, 100 – 120 V |
|---|---|
| Weight | 1.000000 |
| Part No. | LBX-KIM-0294 |
| Supplier Item Code | 35010023 |
| Speed Range | 50 – 6000 rpm |
| Operating Temperature | 0 – 40 °C |
| Product Weight | 12 kg |
| Supply Voltage | 100 – 230 V ± 10 %, 50Hz / 60Hz |
| Technical Data | |
|---|---|
| Funnel Volume | 300 ml |
| Product Discharge | For collection tubes with norm grinding NS29 |
| Grinding Attachments (Convertible) | Blade grinding attachment |
| Motor | Wear-free three-phase motor / Gearless direct drive / Security system auto-off |
| Relative Humidity (Max.) | 80% in storage / 80% during operation |
| Protection Class Acc. to DIN | IP 20 |
| Dimensions (LxWxH) | 325 x 251 x 480 mm |
| EMC Standards | IEC / EN 61000-6-2 / EN 61000-6-3 |
| Safety Standard | IEC / EN 61010-2-51 |
| Sound Level | 70 dB(A) for 6000 rpm |
