Stereo Zoom Microscope KERN OZS 574

We have developed this series specially for general applications with phase contrast method. In addition, the stable, modular construction system of the OBL series offers many more options. Strong and continuously dimmable 3WLED illumination A special fixed, precentred phase contrast condenser as well as field diaphragm give you a simplified Köhler illumination and thereby a powerful phasecontrast display of your sample The large mechanical stage and its specimen holder holds up to two samples at the same time and is quick and easy to focus using a coaxial coarse and fine focusing knob on both sides A large selection of eyepieces, objectives and colour filters, a simple polarizing unit as well as further phase contrast units are available to you as accessories A protective dust cover, eye cups, as well as multilingual user instructions are included in the scope of delivery.,Optical system Parallel Tube type Trinocular Ocular magnifications 10 x Ocular visual field 22 mm Magnification ratio 10,0:1 Zoom [Min] 0,8 x Zoom [Max] 8 x Objectives magnifications 0,8 x - 8 x Illuminance Reflected light, Transmitted Light Illumination type transmitted light LED Illumination intensity transmitted light 3 W Illumination type incident light LED Illumination intensity incident light 3 W Working distance 91 mm Sample height [Max] 100 mm Stand type Pillar Focusing mechanism coarse drive Dimension (W×D×H) 305×300×540 mm
